LWB/E Long Neck Angular Drill Grinder | Corded – Proxxon

WHAT IT IS USED FOR

Proxxon LWB/E  Long-neck angle grinder drill (corded) is an ideal tool for a wide range of applications such as drilling, milling, grinding, polishing, cleaning, cutting, engraving, and marking.

This grinder drill is suitable for right-angle cutting of rods and other metallic materials. It is also perfect for working on more delicate and durable materials like porcelain stoneware and ceramics.

This tool adapts to various cutting, sanding, and finishing needs by using shaft-mounted discs and attaching Velcro-backed pads.

• Proxxon IBS/E: Corded version with variable speed control from 3,000 to 15,000 RPM – Complete with carrying case and collets.
  Includes 7 steel collets – Diameters: 1 – 1.5 – 2 – 2.4 – 3 – 3.2.

MAIN FEATURES OF THE LWB/E GRINDER

Absolute Precision: High concentricity of up to 3/100 mm ensures vibration-free and bounce-free operation.

High-Performance Motor: Balanced DC motor with continuously adjustable electronic speed control, perfectly tailored to work requirements (from 5,000 to 22,000 RPM).

Robust Construction:

• Steel ground shaft mounted on ball bearings for durability and reliability.
• Die-cast aluminum gear housing with a 20 mm collar, compatible with the MICROMOT system for vertical and horizontal supports.
• The motor body is made of fiberglass-reinforced POLYAMIDE for enhanced strength and lightweight handling.

Specifications:

• • Total Length: 270 mm
  • Weight: 550 g

ADVANTAGES

Its compact design makes this drill and milling tool perfect for precision work in limited spaces, allowing for detailed finishing in challenging-to-reach areas.
