Nicolai – Adaptor Flange Ø50 > Small Flange
This adaptor can be used with stubbing wheels small diameter (50 mm) on CNC machine with fitting bore 50 mm + 6 hole.
The choice of the adapter depends on the type of stubbing wheel you are using. The fitting can be:
- with central bore 10 mm + 2 fixing holes
- with central bore 14 mm + 3 fixing holes
| Code | Size | Fitting Machine | Fitting Tool |
|---|---|---|---|
| AZT3450A | Ø38 L60 mm | B50+6HØ6.5/63 | Ø10 + 2 M6/25 |
| AZT2354A | Ø38 L133 mm | B50+6HØ6.5/63 | Ø10 + 2 M6/25 |
| AZT2353A | Ø38 L185 mm | B50+6HØ6.5/63 | Ø10 + 2 M6/25 |
| AZT1381A | Ø38 L224 mm | B50+6HØ6.5/63 | Ø10 + 2 M6/25 |
| AZT4254A | Ø38 L300 mm | B50+6HØ6.5/63 | Ø10 + 2 M6/25 |
| AZT4352A | Ø38 L400 mm | B50+6HØ6.5/63 | Ø10 + 2 M6/25 |
| AZT4353A | Ø38 L500 mm | B50+6HØ6.5/63 | Ø10 + 2 M6/25 |
| AZT5099A | Ø38 L77 mm | B50+6HØ6.5/63 | Ø14 + 3 M6/25 |
| AZT5119A | Ø38 L175 mm | B50+6HØ6.5/63 | Ø14 + 3 M6/25 |
| AZT4661A | Ø38 L210 mm | B50+6HØ6.5/63 | Ø14 + 3 M6/25 |
| AZT4485A | Ø38 L300 mm | B50+6HØ6.5/63 | Ø14 + 3 M6/25 |
| CODE LIST | |||
|---|---|---|---|
| Cod: AZT5099A |
Length: 77 mm | Cod: AZT4485A |
Length: 300 mm |
| Cod: AZT4661A |
Length: 210 mm | Cod: AZT5119A |
Length: 175 mm |
| Cod: AZT4353A |
Length: 500 mm | Cod: AZT4352A |
Length: 400 mm |
| Cod: AZT4254A |
Length: 300 mm | Cod: AZT1381A |
Length: 224 mm |
| Cod: AZT2353A |
Length: 185 mm | Cod: AZT2354A |
Length: 133 mm |
| Cod: AZT3450A |
Length: 60 mm | ||
