Bridge Saw Blades

Diamond Bridge Saw Blades

Bridge saw blades for cutting natural stones, marble, granite, quartz, and porcelain

Extensive selection of high-quality bridge saw blades for the stone cutting including granite, marble, ceramic, quartz and engineered stone.
These diamond blades come from different producers because we want to supply only the best product for that special purpose. When we talk about stone blades it’s not possible to have a single solution, one size doesn’t fit all.

In the stone industry blades are used in a huge range of applications and because of that diamond segments can be very finely adjusted to certain materials, in this way we can optimize cutting performance and tool life.

You find different blades for different materials and in different diameters. Bridge saw blades have a minimum diameter 300 mm (12-inch) and are made for installation in standard bridge saws, banner bridge saws, and cross-cutters.

To buy your blades online you need to select the category of the material to cut and the diameter. In some cases, you’ll find 2 versions for the same blade: silent and standard type.
Use always the blade with the correct diameter to match the RPM of your bridge saw otherwise you’ll experience problems in cutting.

For special purpose cutting blades, or for blades bigger than 625 mm (24-inch)  don’t hesitate to contact us: info@amastone.com

Parameters when cutting marble or granite:

BLADE DIAMETER Ø MARBLE [40-50 M/S] SANDSTONE [55-65 M/S] HARD GRANITE [25-30 M/S] SOFT GRANITE [32-40 M/S]
300 mm 2600 – 3200 Rpm 3500 – 4200 Rpm 1600 – 1900 Rpm 2000 – 2600 Rpm
350 mm 2200 – 2700 Rpm 3000 – 3500 Rpm 1300 – 1700 Rpm 1750 – 2000 Rpm
400 mm 1900 – 2400 Rpm 2600 – 3100 Rpm 1200 – 1500 Rpm 1550 – 1900 Rpm
450 mm 1700 – 2100 Rpm 2300 – 2800 Rpm 1100 – 1300 Rpm 1400 – 1700 Rpm
500 mm 1500 – 1900 Rpm 2100 – 2500 Rpm 1000 – 1200 Rpm 1250 – 1500 Rpm
600 mm 1300 – 1600 Rpm 1700 – 2100 Rpm 800 – 1000 Rpm 1050 – 1300 Rpm
625 mm 1200 – 1500 Rpm 1650 – 2000 Rpm 750 – 950 Rpm 1000 – 1250 Rpm

Parameters when cutting ceramic and porcelain:

BLADE DIAMETER Ø DOUBLE FIRING [55-80 M/S] SINGLE FIRING [45-55 M/S] GRES PORCELAIN [40-50 M/S]
250 mm 2100 – 3000 Rpm 1700 – 2100 Rpm 1500 – 1900 Rpm
300 mm 1750 – 2500 Rpm 1400 – 1750 Rpm 1280 – 1600 Rpm
350 mm 1500 – 2200 Rpm 1250 – 1500 Rpm 1100 – 1400 Rpm
400 mm 1300 – 1900 Rpm 1100 – 1300 Rpm 960 – 1200 Rpm
500 mm 1050 – 1550 Rpm 860 – 1050 Rpm 780 – 960 Rpm
  • Blades for Granite

    Blades for Granite (8)

  • Blades for Marble

    Blades for Marble (2)

  • Blades for Ceramic big tiles

    Blades for Ceramic big tiles (6)

  • Diamond profiled wheels

    Diamond profiled wheels (2)


  • Other products
    Grid View | List View
    Lapitec, Dekton, Neolith Bridge Saw Blades Diamant Boart
    From: 133,00  From: 99,75
    View

    Lapitec, Dekton, Neolith Bridge Saw Blades - Diamant Boart

    High-quality bridge saw blades (discs) for lapitec, neolith and dekton cutting. Available in 2 different diameters, 300 mm (12″) and 350 mm (14″). The standard fitting hole is 50/60 mm. We can supply you your granite blades wita h different hole without additional costs. High qu...
    Brand: Diamant Boart | Height of diamond sector: 10 mm | Application: Dekton, Lapitec, Neolith | Core: Standard steel core
    Different options: verify stock
    Diameter:
    350 mm - 14"
    2 in stock (more shipped in 5-10 days)
    Diameter:
    300 mm - 12"
    3 in stock
