BATTILE PRO Vibrating suction cup | 16V | Montolit

BATTILE PRO 16V vibrating suction cup for tiles and slabs by Montolit

Ideal for ceramic, porcelain, granite, marble, and glass tiles and slabs.

Note: Battile suction cups are not waterproof. Montolit recommends avoiding contact with water or other liquids in order to prevent damage to the electrical components.
The warranty does not cover any damage caused by liquid contact.

Battile PRO thumping  suction cup (removable and rechargeable battery)

Equipped with an easily removable and rechargeable 16V lithium battery, it has a remarkable vibrating power, which can be modulated via a control panel on three different frequencies, optimized for the correct application of the adhesive and the extraction of voids or air bubbles and a contact base in special large non-marking rubber.

Level 1: Red LED on (minimum vibration frequency)
Level 2: Red and yellow LEDs on (medium vibration frequency)
Level 3: Red, yellow and green LEDs all on (maximum vibration frequency)

The suction cup, which can be activated simply with an eccentric lever, allows lifting up to 25 kg and can be kept in depression to vibrate the tile once it has been laid, while the release of the suction cup is recommended to be able to perform the vibration operation with a circular movement from the inside of the tile towards the outside, particularly suitable for large formats or thin slabs.
The particular shape and the double handle allow to keep the load balanced during the lifting and laying of the tile and to best lead Battile-Pro in the thumping phase to optimize its functionality. The inserts in soft-touch material on the handle make the grip ergonomically comfortable and safe.

Battile PRO comes with 2 removable batteries and a vibration expander.

• MODEL: BATTILE PRO
• CAPACITY: 25 kg
• BATTERY CAPACITY: 16 V – 2 Ah
• CHARGING CURRENT: 1 A
• BATTERY CHARGING TIME: 2.5 h
• VIBRATION FREQUENCY: 5,000–12,000 rpm
• VIBRATION INTENSITY: 3 tapping levels
• WEIGHT: 1.35 kg
• SUCTION DIAMETER: 13 cm
• OVERALL DIMENSIONS: 37 × 13 × H 14 cm

If you need other types of suction cups for lifting, go to the category: Lifting Equipment

Accessories & Spare Parts for BATTILE PRO also available:

• BATTILE Vibrating Suction Cup Charger – Montolit
