W-F Series (fixed) RWM electric chain hoist for crane – 250/500 kg lifting capacity
The RWM W-F series is an Italian-made electric hoist produced by RWM. The W series is characterized by its compact dimensions, optimized to make the most of the available vertical space.
Available online in the 250 and 500 kg versions (for other capacities, 125 or 1000 kg, contact us).
The hoist includes a standard 3-meter-long chain, but upon request, it can be ordered with a longer one, as well as for the pendant control cable (the supplied cable is 2 meters long).
The hoist does not include the trolley. If you need the model with a push, electric, or mechanical trolley, contact us at
Specifications for 250 Kg:
- Lifting speed: 1-4 m/min.
- Hook path: 3 meters
- Chain falls: 1, diameter 4 mm
- Equipped with an eye suspension
- Low-voltage 24v system
- Pendant control with a 2-meter cable
- Friction load limiter
- Chain collector
- Voltage: 400 / 50
- FEM class 2m
Specifications for 500 Kg:
- Lifting speed: 1-4 m/min.
- Hook path: 3 meters
- Chain falls: 1, diameter 5 mm
- Equipped with an eye suspension
- Low-voltage 24v system
- Pendant control with a 2-meter cable
- Friction load limiter
- Chain collector
- Voltage: 400 / 50
- FEM class 2m
